FLR6Y-A Automotive Wire FEP Thin Wall Vehicle Electrical Wiring Harness Cable ISO 6722

Short Description:

Send email to us

Product Detail

Product Tags

PRODUCT DESCRIPTION

1.Rated temperature ：-40 °C to +200 °C (3000 h)

2.Rated voltage ：25VAC and 60VDC

3.Reference standard：DIN 72551, ISO 6722

4.Insulation: FEP ( Fluorinated Ethylene Propylene)

5.The vertical flame combustion test complies with：:DIN 72551.5

6.Environmental requirements: RoHS & REACH;

7.Applicable to low tension primary wire of electric system for auto within.Very good oil- and fuel resistance,Very high resistance to atmospheric conditions and ozone,Excellent temperature resistance.

PARAMETER

Conductor 导体			Insulation 绝缘		Maximun Resistance at 20℃ 20℃最大导体电阻Ω/km
Conductor 导体			Insulation 绝缘
mm² 截面	No./mm 线数/最大线径	Nom.Dia. 外径 mm	Min.Thick 最小厚度 mm	Maximum outer diameter 最大外径 mm


0.35	12/0.21	0.90	0.20	1.20	52.0
0.5	16/0.21	1.00	0.22	1.40	37.1
0.75	24/0.21	1.20	0.24	1.70	24.7
1.0	32/0.21	1.35	0.24	1.90	18.5
1.5	30/0.26	1.70	0.24	2.20	12.7
2.5	50/0.26	2.20	0.28	2.70	7.60
4.0	56/0.31	2.75	0.28	3.00	4.70
6.0	84/0.31	3.30	0.32	3.40	3.14
