UL3135 Silicone Rubber Cable High Temperature 200°C Fiberglass Braided Electrical Wire 600V for Industrial and Automotive Applications

PRODUCT DESCRIPTION

1.Stranded, tinned copper conductor, 26AWG - 16AWG .

2.Color-coded Silicone Rubber insulation, covered with Fiberglass braid jacket.

3.Rated temperature: 200℃.

4.Rated voltage: 300V.

5.Good Resistance to acids, alkalies, oils. Low smoke and non-halogen.High flexibility. Easy for wiring works.

6.Refer to standards UL 758, UL1581 & CSA C22.2 No. 210.2, passes CSA FT2 flame test.

7.Uniform insulation thickness of wire to ensure easy stripping and cutting.

8.Environmental testing： pass RoHS

9.Suitable for internal wiring for cooking appliances, lighting equipment, internal combustion engine, electrical heating machines or other appliances working in hot environments.

PRODUCT PARAMETERS
