UL Electronic Cable

  • UL2725 PVC Insulation Cable

    UL2725 PVC Insulation Cable

    UL2725 style 24+28AWG USB cable

    inquirydetail
  • UL1061 HOOK UP WIRE

    UL1061 HOOK UP WIRE

    80ºC 300V SR-PVC INSULATION  WIRE.

    Rated temperature:80ºC

    Rated voltage:300V

    According to:UL subject 758,UL1581

    Solid or Stranded,tinned or bare copper conductor 30AWG-14AWG

    SR-PVC insulation.

    Passes UL VW-1 & CSA FT1 Vertical flame test.

    Uniform insulation thickness of wire to ensure easy stripping and cutting.

    Environmental testing pass RoHS.

    Ground strap lead wire for the internal wiring of electronic equipment.



    inquirydetail
  • UL2517 HOOK UP WIRE

    UL2517 HOOK UP WIRE

    105ºC  300V PVC INSULATION AND JACKET WIRE

    Rated temperature:105ºC
    Rated voltage:300V
    According to:UL subject 758,UL1581
    Solid or Stranded,tinned or bare copper conductor 40AWG
    PVC insulation，PVC Jacket insulation.
    Passes UL VW-1 & CSA FT1 Vertical flame test
    Environmental testing pass RoHS
    Use for general electric equipment

    inquirydetail
  • UL2547 HOOK UP WIRE

    UL2547 HOOK UP WIRE

    80ºC  PVC INSULATION AND JACKET WIRE

    Rated temperature:150ºC
    Rated voltage:300V
    According to:UL subject 758,UL1581
    Solid or Stranded,tinned or bare copper conductor 40AWG
    PVC insulation，PVC Jacket insulation.
    Passes UL VW-1 & CSA FT1 Vertical flame test
    Environmental testing pass RoHS
    Use for general electric equipment

    inquirydetail
  • UL3289 HOOK UP WIRE

    UL3289 HOOK UP WIRE

    150ºC  600V XLPE INSULATION  WIRE

    Rated temperature:150ºC
    Rated voltage:600V
    According to:UL subject 758,UL1581
    Solid or Stranded,tinned or bare copper conductor 30-10AWG
    XLPE  insulation.
    Passes UL VW-1 & CSA FT1 Vertical flame test
    Environmental testing pass RoHS
    Ground strap lead wire for the internal wiring of electronic equipment

    inquirydetail
  • UL3321HOOK UP WIRE

    UL3321HOOK UP WIRE

    150ºC  600V XLPE INSULATION  WIRE

    Rated temperature:150ºC
    Rated voltage:600V
    According to:UL subject 758,UL1581
    Solid or Stranded,tinned or bare copper conductor 30-4/0AWG
    Cross-Linked Polyolefin insulation.
    Passes UL VW-1 & CSA FT1 Vertical flame test
    Environmental testing pass RoHS
    Use for general electric equipment

    inquirydetail
  • UL3173,HOOK UP WIRE

    UL3173,HOOK UP WIRE

    125ºC  600V XLPE INSULATION  WIRE

    Rated temperature:125ºC
    Rated voltage:600V
    According to:UL subject 758,UL1581
    Solid or Stranded,tinned or bare copper conductor 30-10AWG
    XLPE  insulation.
    Passes UL VW-1 & CSA FT1 Vertical flame test
    Environmental testing pass RoHS
    Ground strap lead wire for the internal wiring of electronic equipment

    inquirydetail
  • UL10267 HOOK UP WIRE

    UL10267 HOOK UP WIRE

    105ºC  2000V AC  XLPE INSULATION  WIRE

    Rated temperature:105ºC
    Rated voltage:2000V
    According to:UL subject 758,UL1581
    Solid or Stranded,tinned or bare copper conductor 30-10AWG
    XLPE  insulation.
    Passes UL VW-1 & CSA FT1 Vertical flame test
    Environmental testing pass RoHS
    Ground strap lead wire for the internal wiring of electronic equipment

    inquirydetail
  • UL10198 HOOK UP WIRE

    UL10198 HOOK UP WIRE

    105ºC  300V SOFT PVC INSULATION  WIRE

    Rated temperature:105ºC
    Rated voltage:300V
    According to:UL subject 758,UL1581
    Solid or Stranded,tinned or bare copper conductor 30-4/0AWG
    PVC  insulation.
    Passes UL VW-1 & CSA FT1 Vertical flame test
    Environmental testing pass RoHS
    Ground strap lead wire for the internal wiring of electronic equipment

    inquirydetail
  • UL1571 HOOK UP WIRE

    UL1571 HOOK UP WIRE

    80ºC  30V PVC INSULATION  WIRE

    Rated temperature:80ºC
    Rated voltage:30V
    According to:UL subject 758,UL1581
    Solid or Stranded,tinned or bare copper conductor MIN 50AWG
    PVC OR SR-PVC insulation.
    Passes UL VW-1 & CSA FT1 Vertical flame test
    Environmental testing pass RoHS
    Ground strap lead wire for the internal wiring of electronic equipment

    inquirydetail
  • UL1283 HOOK UP WIRE

    UL1283 HOOK UP WIRE

    105ºC  600V PVC INSULATION  WIRE

    Rated temperature:105ºC

    Rated voltage:600V

    According to:UL subject 758,UL1581,CSA C22.2

    Solid or Stranded,tinned or bare copper conductor 8~2AWG

    PVC insulation.

    Passes UL VW-1 & CSA FT1 Vertical flame test

    Environmental testing pass RoHS

    The wire can use for the Internal wiring of appliances where exposed to oil at a temperature not exceeding (60°C or 80°C, whichever is applicable)

    inquirydetail
  • UL1032 HOOK UP WIRE

    UL1032 HOOK UP WIRE

    90ºC 1000V PVC INSULATION WIRE

    Rated temperature:90ºC

    Rated voltage:1000V

    According to:UL subject 758,UL1581,CSA C22.2

    Solid or Stranded,tinned or bare copper conductor30AWG-2000kcmil

    PVC insulation.

    Passes UL VW-1 & CSA FT1 Vertical flame test

    Uniform insulation thickness of wire to ensure easy stripping and cutting.

    Environmental testing pass RoHS

    The wire can use for the Internal wiring of appliances where exposed to oil at a temperature not exceeding (60°C or 80°C, whichever is applicable).

    inquirydetail
26 Total
